new old stock
0.625" Input Diameter, 0.625" Output Diameter, Shaft Input, Shaft Output
Family: Hub city bevel gear drives
Gear Drive Size: M2
Gear type: ST
Height: 4
Housing dimensions: (L)4.796875 x (H)3.1875 x (W)4.131
Housing height (in): 3.188
Housing length (in): 4.797
Housing material: Cast Iron
Housing width (in): 4.131
HP Range: 1 to 1-1/2 (< 2)
Input diameter: 0.625
Input HP: 1.04
Input type: Shaft
Length: 9
Maximum input HP: 1.04 @ 1750 RPM
Model: M2
Output diameter: 0.625
Output RPM: 875
Output shaft direction: Double
Output Torque Range (in-lb): < 250 in lbs
Output torque rating: 75
Output type: Shaft
Product line: Bevel gear drives
Product type: Right angle
Ratio: 2:1
Service factor: 1
Style: A,B
Width: 9
